Schneider M9F11325 Miniature circuit breaker

• Rated Current: 25A
• Tripping Curve: C Type
• Rated Breaking Capacity: 10kA @ 415VAC (per EN/IEC 60947-2)
• Operational Voltage (Ue): 240VAC
• Rated Insulation Voltage (Ui): 500VAC
• Impulse Withstand Voltage (Uimp): 6kV
• Frequency: 50Hz / 60Hz
• Electrical Endurance: 10,000 cycles
• Mechanical Endurance: 20,000 cycles
• Mounting: DIN rail mountable
• Width: 54mm (6 × 9mm modules)
• Product Dimensions: 54mm (W) × 81mm (H) × 72mm (D)
• Weight: 0.36kg
• Pollution Degree: 3
• Overvoltage Category: IV

This Multi9 C60N is a low voltage miniature circuit breaker (MCB). It is a 3P circuit breaker with 3 protected poles, 25A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10kA at 415VAC conforming to EN/IEC 60947-2 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. It has been designed to offer enhanced protection by preventing, protecting people and equipment from electrical threats. This product protects from short circuit, earth leakage and overload. Its fast closing mechanism, overvolatge resistance and high performance limitation improve its service life. This product is dedicated for original equipment manufacturers (OEM) and control panel builders. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The operating frequency is 50Hz or 60Hz. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is light grey (RAL7035). The dimensions are (W) 54mm x (H) 81mm x (D) 72mm. The weight is 0.36kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 80°C.
